Fiber Optic Video Converter

FO-XVC

3G-HD-SDI Video to Fiber Optic Converter

The converters allows the transport of SDI, HD-SDI, and 3G SDI over distances up to 10km using standard single-mode fiber optic LC cable.

This models, offers unmatched flexibility and cost efficiency. The dual channel models allow the conversion of 2 channels – perfect for 3D, dual-link SDI, or 2 completely independent SDI channels (for example, SD, HD, and 3G can be mixed in any combination). Also, the converters offer electrical isolation useful for eliminating ground loop problems.

Fiber Optic to 3G-HD-SDI Video Converter

The converters allows the transport of SDI, HD-SDI, and 3G SDI over distances up to 10km using standard single-mode fiber optic LC cable.

3G-HD-SDI Video to Fiber Optic Converter

Specification
Formats 3Gb, 1.5Gb, 270Mb, Auto Select
Video Inputs SDI (SMPTE 259/292/296/424), 8x BNC
Video Outputs 8x Single mode optical fiber: LC connectors
Power Supply 5VDC 0.5A
Dimensions (WxDxH) 300 x 155 85 mm
Weight <1Kg
Housing Alluminium
Colour Black/White
Input/Output Return Loss (BNC) >15db, 270Mb – 3Gb

Fiber Optic to 3G-HD-SDI Video Converter

Specification
Formati 3Gb, 1.5Gb, 270Mb, Auto Select
Ingressi Video SDI (SMPTE 259/292/296/424), 8x BNC
Uscite Video 8x Fibra ottica mono modale: connettori LC
Tensione di alimentazione 5VDC 0.5A
Dimensioni (WxDxH) 300 x 155 x 85 mm
Peso <1Kg
Contenitore Alluminio
Colore Bianco/Nero
Input/Output Return Loss (BNC) >15db, 270Mb – 3Gb
